Place of Origin: China
Housing material: PVC
Application: Crane Power Transmission
Certificate: ISO9001
Rated Current: 50-120A
Color: Orange
Phase: 3 Phase, 4 Phase, 6 Phase
Conductor Cross Section: 10,16,25,35 Square mm
Temperature: up to 60℃ and 90℃ option
Name: Seamless crane power supply busbar
Material
Conducive material: 99.99% Oxygen-free copper
Housing material: PVC (heat resistance property 70℃--40℃ below)
Features
Quick and Easy Assembly
Excellent Electrical Conductivity
CAD / CAM Designed for Stable Quality
Advantage
1. 99.99% Oxygen-free copper
2. No joint, continuous power supply
3. Small space, Low noise
4. Low voltage drop
5. Stable operation, fast speed, good conductivity and contact performance
6. Easy to install, replace and transport
7. Long service life
8. The minimum bend radius reaches 750mm
Application
With advanced technology, skillful manufacture and beautiful design, the Power Supply Trolley Slide Wire is suitable for machinery works, small size steel factory, low power hoisting, cranes, monorails, electric hoists, electric tools, stacking systems and wildly used in the Lifting industry. (ambient temperature is< 55℃)
Specifications
| Type | Poles | Conductor Cross Section (mm2) | Max Current (A) |
| 761003 | 3 | 3*10mm2 | 50A |
| 761503 | 3 | 3*15mm2 | 80A |
| 752003 | 3 | 3*20mm2 | 100A |
| 762503 | 3 | 3*25mm2 | 120A |
| 763503 | 3 | 3*35mm2 | 140A |
| 761004 | 4 | 4*10mm2 | 50A |
| 761504 | 4 | 3*15mm2+1*10mm2 | 80A |
| 762004 | 4 | 3*20mm2+1*10mm2 | 100A |
| 762504 | 4 | 3*25mm2+1*12.5mm2 | 120A |
| 763504 | 4 | 3*35mm2+1*15mm2 | 140A |
| 761006 | 6 | 6*10mm2 | 50A |
| 751506 | 6 | 6*15mm2 | 80A |
Notes:The foregoing attached table shall only be used for reference. The actual application shall be appropriately modified according to customers' requirements.
